适合40-80克各种纸张
2.人机界面调节袋子长度
3.伺服系统PLC控制一定范围内袋子的任意长度
4.精确的色标跟踪系统
5.采用点齿刀打断
Model | YT-800 | YT-1000 | YT-1100 |
Max material width最大印料宽度 | 800mm | 1000mm | 1100mm |
Max effective printing width有效印刷宽度 | 760mm | 960mm | 1060mm |
Range of repeat printing length 印刷品长度范围 | 2280-1000mm | 2280-1000mm | 2280-1000mm |
Printing speed 印刷速度 | 5-100pcs/min | 5-100pcs/min | 5-100pcs/min |
机器功率 total power | 16kw | 16kw | 19kw |
机器重量 weight | 1500kg | 1600kg | 1700kg |
Machine dimensions机器尺寸 | 2500 x 2300 x 2000mm | 2500 x 2500 x 2000mm | 2500 x 2700 x 2000mm |
备注remarks:2色 two color, 4色 four color , 6色 six color
型号MODEL： | JD-400 | JD-650 | JD-850 |
纸张克重bag weight: | 40-80g/m2 | 40-80g/m2 | 40-80g/m2 |
切袋长度tube length: | 160-420mm | 220-650mm | 220-850mm |
制袋宽度bag width: | 70-260mm | 70-300mm | 80-350mm |
制袋速度speed: | 60-400bags/min | 60-400bags/min | 60-400bags/min |
整机重量weight: | 3000kg | 4200kg | 5200kg |
卷筒放料宽度max paper roll width: | 260-720mm | 260-840mm | 260-960mm |
电机power: | 8kw | 8kw | 8kw |
插边尺寸insert size: | 20-120mm | 20-120mm | 20-120mm |
机器尺寸 长x宽x高machine size (L*W*H): | 7000x2100x1900mm | 7500*2100*2000 | 7800*2100*2000 |
