Four Color Flexographic Printing MachineFour Color Flexographic Printing Machine

Four Color Flexographic Printing Machine



Model: ZXYT-41000

Mob: 0086 13655772222
Tel: 0086-577-63081111
Fax: 0086-577-63778011
Email: admin@zhuxin.cn admin@chinazxin.com

Four Color Flexographic Printing Machine



Model: ZXYT-41000
PRODUCT INFORMATION

Characteristics:

This machine used to print logo, stickers logo computer form bill  aluminum foil milk kraft paper ,battery film,carton paper and so on, printed raw material thickness range to be 40-200g/m Printing machine functional diversification,can do double-face print adhesive sticker peeling print UV glazing indentation ,die cut, coating ,gold stamping, slitting and so on technology process.This is idea printing equipment! for wine package cigarette box, medicine box, make-up box, milk box juice box,carton package(logo,box,bag.carton )


Main Technical Variables:

<-------- Can Move Left or Right -------->

Model

ZXYT-41000

Maximum  paper width

39.96"  (1015mm)

Maximum  printing width

Printing  repeat

39.37"  (1000mm)

11”-  26" (279.4-660mm)

Maximum  unwinder diameter

Maximum  rewinder diameter

60"  ( 1524mm)

60"  (1524mm)

Gearing

Maximum  mechanical speed

1/8CP,3  175mm

150m/min

Drive

Lubricating system

11kw

Automatic



Control  panel

Air  pressure



In the  front of the pres

100PSI(O.7Mpa)

Power  requirement

Suitable  material

380VAC3ph  50HZ

40-200gsm  paper、Film,non-woven  fabric,elc

Machine  color

Grey and  white
